- Place of Origin: SHANDONG
- Brand Name: FENGNI
- Model Number: FNGQ-90/120
The machine is the introduction of the advanced technology.and equipment gasoline engine of 6.5 HP(4.8KW).The product is suitable for storal area, orchard, lawn trimming and cutting grass.To use the worm gear and worm rotation, Soft tensioning clutch, Flexible movement, Easy operation, Higher efficiency.
Type
| FNGQ-90/120 | ||
Matching Power
| 6.5HP(4.8kw) | Efficiency | 0.21~0.28h㎡/h |
Cutting Width
| 900-1200mm | Workingspeed | 2.4km/h |
Stubble height
| 30-80mm | Overall size | 1500×1200×800mm |
Weight
| 63kg | Ececution standard | GB/T10940-2008 |
Loading Qty. 20'/40'/40HQ(pcs)
| 96/192/216 |
The machine can install cutting knife width for 90cm or 120cm.
Main spare parts:
1、Engine brand is LIFAN168F-2,which is famous a brand. And strong driving force.
2、The cutting knife was used carbon tool steel of T8,T10.The blade with sharp teeth, to avoid stalk slipping.
3、The turbo takes SnCu material, wear-resisting, long service life.
Product Introduction:
Taian Fengni Industrail &Trade Co.,ltd produced in the centraldriving force for reciprocating hand T-dual-wheel drive mower, it applies toagricultural / pastoral flat and mountain grassland, grassland hills, mainlyfor trimming the lawn, grass harvesting , pastoral management, such as shrubtrimming. Air-cooled four-stroke engine for the gasoline engine, startrebounding by the device is switched on. Transmission smooth, no energy loss.Environmental design, in line with the European Ⅱ emission standard. Gearbox output toachieve the use of dedicated walking CVT clutch. Cutter from eccentric crankmounted on the wheel directly driven by a knife to be on the slide movement,eccentric wheel through a belt transmission gearbox and the front of thechassis power output belt connected to the use of combination ofsub-clutch-type gear-type clutch. Reciprocating cutter clutch control, throttlecontrol switch, emergency off switch control handles are located in operation,the hand adjustable up and down in vertical direction, cutting blade fromrefined from special chrome steel, wear resistance, and blade gap can be Bladepressure adjustment device pads. Smooth and accurate cutting knife-oriented, inorder to increase the whole road adhesion, the use of human-shaped rubbertires. Installation of transmission shield, the use of security. It has a widerange of uses, smooth operation, low power consumption, cutting quality, theadvantages of not blocking knife.
